🔁 Divergence Detector (RSI + MACD)

//version=5
indicator("🔁 Divergence Detector (RSI + MACD)", overlay=true)

// === INPUTS ===
useRSI = input.bool(true, "Enable RSI Divergence")
useMACD = input.bool(true, "Enable MACD Divergence")

rsiSource = input.source(close, "RSI Source")
rsiLength = input.int(14, "RSI Length")

macdSrc = input.source(close, "MACD Source")
macdFast = input.int(12, "MACD Fast Length")
macdSlow = input.int(26, "MACD Slow Length")
macdSig = input.int(9, "MACD Signal Smoothing")

lookback = input.int(20, "Lookback Range")

// === INDICATOR CALCULATIONS ===
rsi = ta.rsi(rsiSource, rsiLength)

[macdLine, signalLine, _] = ta.macd(macdSrc, macdFast, macdSlow, macdSig)
macdHist = macdLine - signalLine

// === DIVERGENCE DETECTION ===
var float lastLowPrice = na
var float lastLowRSI = na
var float lastLowMACD = na

var float lastHighPrice = na
var float lastHighRSI = na
var float lastHighMACD = na

bullDivRSI = false
bearDivRSI = false
revBullDivRSI = false
revBearDivRSI = false

bullDivMACD = false
bearDivMACD = false
revBullDivMACD = false
revBearDivMACD = false

// Detect bottoms (for Bullish Divergences)
if ta.lowestbars(low, 3) == 1
// Store recent low
bullCondition = true
// RSI
if useRSI
if not na(lastLowRSI)
bullDivRSI := (low < lastLowPrice) and (rsi > lastLowRSI)
revBullDivRSI := (low > lastLowPrice) and (rsi < lastLowRSI)
lastLowPrice := low
lastLowRSI := rsi
// MACD
if useMACD
if not na(lastLowMACD)
bullDivMACD := (low < lastLowPrice) and (macdHist > lastLowMACD)
revBullDivMACD := (low > lastLowPrice) and (macdHist < lastLowMACD)
lastLowMACD := macdHist

// Detect tops (for Bearish Divergences)
if ta.highestbars(high, 3) == 1
// RSI
if useRSI
if not na(lastHighRSI)
bearDivRSI := (high > lastHighPrice) and (rsi < lastHighRSI)
revBearDivRSI := (high < lastHighPrice) and (rsi > lastHighRSI)
lastHighPrice := high
lastHighRSI := rsi
// MACD
if useMACD
if not na(lastHighMACD)
bearDivMACD := (high > lastHighPrice) and (macdHist < lastHighMACD)
revBearDivMACD := (high < lastHighPrice) and (macdHist > lastHighMACD)
lastHighMACD := macdHist

// === PLOTS ===
// RSI-based Divergences
plotshape(bullDivRSI, title="Bullish RSI Div", location=location.belowbar, color=color.green, style=shape.labelup, text="RSI\nBull Div")
plotshape(bearDivRSI, title="Bearish RSI Div", location=location.abovebar, color=color.red, style=shape.labeldown, text="RSI\nBear Div")
plotshape(revBullDivRSI, title="Rev Bull RSI", location=location.belowbar, color=color.lime, style=shape.triangleup, text="RSI\nRevBull")
plotshape(revBearDivRSI, title="Rev Bear RSI", location=location.abovebar, color=color.orange, style=shape.triangledown, text="RSI\nRevBear")

// MACD-based Divergences
plotshape(bullDivMACD, title="Bullish MACD Div", location=location.belowbar, color=color.navy, style=shape.labelup, text="MACD\nBull Div")
plotshape(bearDivMACD, title="Bearish MACD Div", location=location.abovebar, color=color.maroon, style=shape.labeldown, text="MACD\nBear Div")
plotshape(revBullDivMACD, title="Rev Bull MACD", location=location.belowbar, color=color.blue, style=shape.triangleup, text="MACD\nRevBull")
plotshape(revBearDivMACD, title="Rev Bear MACD", location=location.abovebar, color=color.purple, style=shape.triangledown, text="MACD\nRevBear")

Open-source script

In true TradingView spirit, the creator of this script has made it open-source, so that traders can review and verify its functionality. Kudos to the author! While you can use it for free, remember that republishing the code is subject to our House Rules.
