PINE LIBRARY

TTB_TableBuilder

Library "TTB_TableBuilder"
A helper library to make it simpler to create tables in pinescript

DefaultDarkStyle()

method Size(this, width, height)
Change the size (width, height) of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
width (int)
height (int)
Returns: Cell

method Size(this, width, height)
Change the width of all cells in that row
Namespace types: Row
Parameters:
this (Row)
width (int)
height (int)
Returns: Row

method Width(this, width)
Change the width of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
width (int)
Returns: Cell

method Width(this, width)
Change the width of all cells in that row
Namespace types: Row
Parameters:
this (Row)
width (int)
Returns: Row

method Height(this, height)
Change the height of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
height (int)
Returns: Cell

method Height(this, height)
Change the height of all cells in that row
Namespace types: Row
Parameters:
this (Row)
height (int)
Returns: Row

method Text(this, text_)
Change the text of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
text_ (string)
Returns: Cell

method Text(this, c0, c1, c3, c4, c5, c6, c7, c8, c9, c10, c11, c12, c13, c14, c15, c16, c17, c18, c19, c20, c21, c22, c23, c24, c25, c26, c27, c28, c29)
Set text
Namespace types: Row
Parameters:
this (Row)
c0 (string): ... c29
c1 (string)
c3 (string)
c4 (string)
c5 (string)
c6 (string)
c7 (string)
c8 (string)
c9 (string)
c10 (string)
c11 (string)
c12 (string)
c13 (string)
c14 (string)
c15 (string)
c16 (string)
c17 (string)
c18 (string)
c19 (string)
c20 (string)
c21 (string)
c22 (string)
c23 (string)
c24 (string)
c25 (string)
c26 (string)
c27 (string)
c28 (string)
c29 (string)
Returns: Row

method TextSize(this, text_size)
Change the text size of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
text_size (string)
Returns: Cell

method TextSize(this, text_size)
Set text size
Namespace types: Row
Parameters:
this (Row)
text_size (string)
Returns: Row

method TextColor(this, c)
Change the text color of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
c (color)
Returns: Cell

method TextColor(this, text_color)
Change the text color of all cells in that row
Namespace types: Row
Parameters:
this (Row)
text_color (color)
Returns: Row

method Bg(this, c)
Change the background color of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
c (color)
Returns: Cell

method Bg(this, bg)
Change the background color of all cells in that row
Namespace types: Row
Parameters:
this (Row)
bg (color)
Returns: Row

method Font(this, text_font_family)
Change the font family of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
text_font_family (string)
Returns: Cell

method Font(this, text_font_family)
Change the width of all cells in that row
Namespace types: Row
Parameters:
this (Row)
text_font_family (string)
Returns: Row

method AlignH(this, halign)
Change the horizontal align of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
halign (string)
Returns: Cell

method AlignH(this, halign)
Change the horizontal align of all cells in that row
Namespace types: Row
Parameters:
this (Row)
halign (string)
Returns: Cell

method AlignV(this, valign)
Change the vertical align of the table cell.
Namespace types: Cell
Parameters:
this (Cell)
valign (string)
Returns: Cell

method AlignV(this, valign)
Change the vertical of all cells in that row
Namespace types: Row
Parameters:
this (Row)
valign (string)
Returns: Cell

method C(this, column)
Get the cell corresponding to the column number
Namespace types: Row
Parameters:
this (Row)
column (int)
Returns: Cell

method C(this, column, row)
Namespace types: Table
Parameters:
this (Table)
column (int)
row (int)

method R(this, row)
Namespace types: Table
Parameters:
this (Table)
row (int)

method Style(this, style)
Namespace types: Table
Parameters:
this (Table)
style (TableStyle)

method Position(this, position)
Namespace types: Table
Parameters:
this (Table)
position (string)

new(position, columns, rows, style)
Parameters:
position (string)
columns (int)
rows (int)
style (TableStyle)

CellStyle
Fields:
text_color (series__color)
text_halign (series__string)
text_valign (series__string)
text_size (series__integer)
bgcolor (series__color)
tooltip (series__string)
text_font_family (series__string)

TableStyle
Fields:
bgcolor (series__color)
frame_color (series__color)
frame_width (series__integer)
border_color (series__color)
border_width (series__integer)
default_cell_style (|CellStyle|#OBJ)

Cell
Fields:
ref (series__table)
column (series__integer)
row (series__integer)

Row
Fields:
ref (series__table)
row (series__integer)
cells (array__|Cell|#OBJ)

Table
Fields:
body (series__table)
rows (array__|Row|#OBJ)
